Epoxies & Mastics

Proven Performance & Durability

Vortex Companies delivers exceptional protection and rehabilitation solutions with our advanced Epoxies and Mastics, featuring leading products like Structure Guard® and Chimney Guard™. Designed for both new construction and rehabilitation projects, these products are crafted from 100% solids epoxy and urethane hybrids, ensuring robust, long-lasting performance under the most challenging conditions.

Our products are third-party tested and approved, ensuring compliance with the highest industry standards. With over 20 years of proven performance in the field, our epoxies and mastics have demonstrated their ability to withstand the test of time, providing dependable solutions for a wide range of municipal and industrial applications.

At Vortex, we are committed to innovation and quality, ensuring that each product not only meets but exceeds the rigorous demands of infrastructure protection and rehabilitation. Whether it’s enhancing the durability of a manhole or sealing a pump station, our epoxies and mastics are designed to deliver superior results, project after project.

Structure Guard®

Structure Guard® is a 100% solids, high-build epoxy coating formulated to provide long-term corrosion protection and structural enhancement for manholes, pump stations, treatment plants or any wastewater infrastructure subject to high levels of corrosion and/or abrasion to include both municipal and industrial applications.

  • Manholes
  • Pump stations
  • Treatment plants
  • Wastewater infrastructure subject to high levels of corrosion and/or abrasion

Structure Guard® - Water

Structure Guard® – Water is a 100% solids epoxy coating made for plural component spray application. NSF 61 certified for pipe as small as 4″ diameter and tanks 50 gallons and larger.

  • Concrete and steel potable water tanks
  • Potable water pipelines
  • Raw water tanks
  • Raw water pipelines
  • Fiberglass potable water tanks

Structure Guard®-RS

Structure Guard®-RS is a 100% solid, high-build, rapid set epoxy coating formulated to provide long-term corrosion protection and structural enhancement. Structure Guard-RS sets fast for a quick return-to-service in the most aggressive and turbulent environments.



  • Manholes
  • Pump stations
  • Treatment plants or any wastewater infrastructure subject to high levels of corrosion and/or abrasion

Structure Guard®-FM

Structure Guard®-FM is a 100% solids epoxy mastic used to protect new infrastructure and to rehabilitate existing, damaged, infrastructure. Structure Guard-FM is best applied using a trowel.

  • Manholes
  • Wet wells
  • Vaults & septic tanks
  • Steel substrates
  • Floor and wall penetrations/cracks
  • Simple spot repair
  • Extreme bonding to nearly all substrates
  • Fast curing
  • Easy workability
  • 1/4” build capability with no sag

Structure Guard®-QS

Structure Guard®-QS is a quick-spray, 100% solids, high-build epoxy coating formulated to provide long-term corrosion protection and structural enhancement for manholes, pump stations, treatment plants or any wastewater infrastructure subject to high levels of corrosion and/or abrasion. Structure Guard-QS sets fast for a quick return-to-service in the most aggressive and turbulent environments. It finishes smooth to enhance flow and is utilized as an interior or exterior pipe lining.

  • Manholes
  • Pump stations
  • Treatment plants or any wastewater infrastructure subject to high levels of corrosion and/or abrasion

Structure Guard®-FB

Quadex® Structure Guard®-FB is an ultra high build epoxy mastic, designed to fill gaps and voids in both new infrastructure and existing damaged infrastructure. This 100% solids formula is an ideal underlayment material for use in combination with Quadex Repair Materials. For optimal installation, trowel application is required.

  • Manholes, wet wells, vaults & septic tanks
  • Steel substrates
  • Floor and wall penetrations/cracks
  • Simple spot repair
  • Extreme bonding to nearly all substrates
  • Fast curing
  • Easy workability
  • 2” | 50.8mm build capability with no sag
  • Void and Gap fill

Chimney Guard

Chimney Guard is a 100% solids epoxy/urethane hybrid designed to provide a highly flexible and securely bonded seal prepared to address heavy traffic loading, extreme freeze thaw and infiltration.

  • High-build monolithic coating / 100 mils per coat
  • One step, durable chimney seal
  • Superior adhesion to steel, concrete and brick
  • Permanent flexibility at low temperature
  • Advanced elongation properties
  • Extended work time

Flex Guard®

Flex Guard® is a 100% solids flexible urethane/epoxy hybrid. The extreme flexibility of Flex Guard makes it the best solution for the most extreme conditions. A 100-150% elongation allows it to be applied where other coatings fail.

Flex Guard exhibits excellent adhesion to steel and concrete; providing superior protection for tanks that typically experience freeze thaw and temperature fluctuation.

Parsonpoxy SEL-80

Parsonpoxy SEL-80 is a 100% solids, two component high-build epoxy coating designed to be applied over brick, concrete or metal structures. It provides excellent protection and abrasion resistance for concrete and steel sewage structures such as manholes, wet wells, digesters and clarifiers, along with mixer blades, shafts and other steel machinery components in contact with aggressive liquids.

  • Contains no flammable solvents or VOCs
  • Apply to horizontal or vertical surfaces
  • Effective on interior and exterior surfaces
  • Apply to new and existing concrete and metal surfaces
  • Excellent chemical resistance

Parsonpoxy FP+

Parsonpoxy FP+ is a two-component, flexible, high-strength, corrosion-resistant epoxy/urethane hybrid product used for repairing sanitary sewer manhole chimney sections and joints, either interior or exterior.

  • Dries durable, flexible and waterproof
  • Non-toxic — 100% solids
  • Chemically resistant
  • No primer required
  • Pre measured kit — no guesswork
  • Easy application
  • Elongation of 600%
